Activiti 5.9 User Guide

A signal can either be thrown by a process instance using a bpmn construct or programmatically using java API. The following methods on the org.activiti.engine.RuntimeService can be used to throw a signal programmatically:

RuntimeService.signalEventReceived(String signalName);
RuntimeService.signalEventReceived(String signalName, String executionId);


The difference between signalEventReceived(String signalName); and signalEventReceived(String signalName, String executionId); is that the first method throws the signal globally to all subscribed handlers (broadcast semantics) and the second method delivers the signal to a specific execution only.

A signal event can be caught by an intermediate catch signal event or a signal boundary event.

 List<Execution> executions = runtimeService.createExecutionQuery()
      .signalEventSubscription("alert")
      .list();


The following is an example of two separate processes communicating using signals. The first process is started if an insurance policy is updated or changed. After the changes have been reviewed by a human participant, a signal event is thrown, signaling that a policy has changed:

This event can now be caught by all process instances which are interested. The following is an example of a process subscribing to the event.

Note: it is important to understand that a signal event is broadcast to all active handlers. This means in the case of the example given above, that all instances of the process catching the signal would receive the event. In this case this is what we want. However, there are also situations where the broadcast behavior is unintended. Consider the following process:

The pattern described in the process above is not supported by activiti. The idea is that the error thrown while performing the "do something" task is caught by the boundary error event and would be propagated to the parallel path of execution using the signal throw event and then interrupt the "do something in parallel" task. So far activiti would perform as expected. The signal would be propagated to the catching boundary event and interrupt the task. However, due to the broadcast semantics of the signal, it would also be propagated to all other process instances which have subscribed to the signal event. In this case, this might not be what we want.

Note: the signal event does not perform any kind of correlation to a specific process instance. On the contrary, it is broadcast to all process instances. If you need to deliver a signal to a specific process instance only, perform correlation manually and use signalEventReceived(String signalName, String executionId) and the appropriate query mechanisms.

At the moment, activiti supports message events only for starting process instances. To support this, the following methods exist on the RuntimeService:

ProcessInstance startProcessInstanceByMessage(String messageName);
ProcessInstance startProcessInstanceByMessage(String messageName, Map<String, Object> processVariables);
ProcessInstance startProcessInstanceByMessage(String messageName, String businessKey, Map<String, Object< processVariables);

At the moment activiti only supports message start events. A message start event catches a message with a given name and starts a process instance. The payload of the message is added as process variables to the process instance. Since a message must be directed at a single receiver, activiti only allows a single process definition to be deployed for a given message name.

ProcessDefinition processDefinition = repositoryService.createProcessDefinitionQuery()
      .messageEventSubscription("newCallCenterBooking")
      .singleResult();


The following is an example of a process which can be started using two different messages:

This is useful if the process needs alternative ways to react to different start events but eventually continues in a uniform way.

A 'none' start event technically means that the trigger for starting the process instance is unspecified. This means that the engine cannot anticipate when the process instance must be started. The none start event is used when the process instance is started through the API by calling one of the startProcessInstanceByXXX methods.

ProcessInstance processInstance = runtimeService.startProcessInstanceByXXX();

Note: a subprocess always has a none start event.

A none start event is visualized as a circle with no inner icon (i.e. no trigger type).

The XML representation of a none start event is the normal start event declaration, without any sub-element (other start event types all have a sub-element declaring the type).

<startEvent id="start" name="my start event" />

formKey: references to a form template that users have to fill in when starting a new process instance. More information can be found in the forms section Example:

<startEvent id="request" activiti:formKey="org/activiti/examples/taskforms/request.form" />

A timer start event is used to create process instance at given time. It can be used both for processes which should start only once and for processes that should start in specific time intervals.

Note: a subprocess cannot have a timer start event.

Note: start timer event is scheduled as soon as process is deployed. There is no need to call startProcessInstanceByXXX, although calling start process methods is not restricted and will cause one more starting of the process at the time of startProcessInstanceByXXX Invocation.

A none start event is visualized as a circle with clock inner icon.

The XML representation of a timer start event is the normal start event declaration, with timer definition sub-element. Please refer to timer definitions for configuration details. for details on configuration details.

Example: process will start 4 times, in 5 minute intervals, starting on 11th march 2011, 12:13

        <startEvent id="theStart">
            <timerEventDefinition>
                <timeCycle>R4/2011-03-11T12:13/PT5M</timeCycle>
            </timerEventDefinition>
        </startEvent>


Example: process will start once, on selected date

        <startEvent id="theStart">
            <timerEventDefinition>
                <timeDate>2011-03-11T12:13:14</timeDate>
            </timerEventDefinition>
        </startEvent>


A message start event can be used to start a process instance using a named message. This effectively allows us to select the right start event from a set of alternative start events using the message name.

When deploying a process instance with one or more message start events, the following considerations apply:

When starting a process instance, a message start event can be triggered using the following methods on the RuntimeService:

ProcessInstance startProcessInstanceByMessage(String messageName);
ProcessInstance startProcessInstanceByMessage(String messageName, Map<String, Object> processVariables);
ProcessInstance startProcessInstanceByMessage(String messageName, String businessKey, Map<String, Object< processVariables);


The messageName is the name given in the name attribute of the message element referenced by the messageRef attribute of the messageEventDefinition. The following considerations apply when starting a process instance:

A message start event is visualized as a circle with a message event symbol. The symbol is unfilled, to visualize the catching (receiving) behavior.

The XML representation of a message start event is the normal start event declaration with a messageEventDefinition child-element:

<definitions id="definitions"
  xmlns="http://www.omg.org/spec/BPMN/20100524/MODEL"
  xmlns:activiti="http://activiti.org/bpmn"
  targetNamespace="Examples"
  xmlns:tns="Examples">

  <message id="newInvoice" name="newInvoiceMessage" />

  <process id="invoiceProcess">

    <startEvent id="messageStart" >
    	<messageEventDefinition messageRef="tns:newInvoice" />
    </startEvent>
    ...
  </process>

</definitions>

An error start event can be used to trigger an event subprocess. An error start event cannot be used for starting a process instance.

An error start event is always interrupting.

A error start event is visualized as a circle with an error event symbol. The symbol is unfilled, to visualize the catching (receiving) behavior.

The XML representation of an error start event is the normal start event declaration with an errorEventDefinition child-element:

<startEvent id="messageStart" >
	<errorEventDefinition errorRef="someError" />
</startEvent>

A 'none' end event means that the result thrown when the event is reached is unspecified. As such, the engine will not do anything extra besides ending the current path of execution.

A none end event is visualized as a circle with a thick border with no inner icon (no result type).

The XML representation of a none end event is the normal end event declaration, without any sub-element (other end event types all have a sub-element declaring the type).

<endEvent id="end" name="my end event" />

When process execution arrives in an error end event, the, the current path of execution is ended and an error is thrown. This error can caught by a matching intermediate boundary error event. In case no matching boundary error event is found, the execution semantics default to the none end event semantics.

An error end event is visualized as a typical end event (circle with thick border), with the error icon inside. The error icon is completely black, to indicate the throwing semantics.

And error end event is represented as an end event, with a errorEventDefinition child element.

<endEvent id="myErrorEndEvent">
  <errorEventDefinition errorRef="myError" />
</endEvent>


The errorRef attribute can reference an error element that is defined outside the process:

<error id="myError" errorCode="123" />
...
<process id="myProcess">
...


The errorCode of the error will be used to find the matching catching boundary error event. If the errorRef does not match any defined error, then the errorRef is used as a shortcut for the errorCode. This is an Activiti specific shortcut. More concretely, following snippets are equivalent in functionality.

<error id="myError" errorCode="error123" />
...
<process id="myProcess">
...
  <endEvent id="myErrorEndEvent">
    <errorEventDefinition errorRef="myError" />
  </endEvent>


is equivalent with

<endEvent id="myErrorEndEvent">
  <errorEventDefinition errorRef="error123" />
</endEvent>


The cancel end event can only be used in combination with a bpmn transaction subprocess. When the cancel end event is reached, a cancel event is thrown which must be caught by a cancel boundary event. The cancel boundary event then cancels the transaction and triggers compensation.

A cancel end event visualized as a typical end event (circle with thick outline), with the cancel icon inside. The cancel icon is completely black, to indicate the throwing semantics.

A cancel end event is represented as an end event, with a cancelEventDefinition child element.

<endEvent id="myCancelEndEvent">
  <cancelEventDefinition />
</endEvent>


A timer boundary event acts as a stopwatch and alarm clock. When an execution arrives in the activity where the boundary event is attached to, a timer is started. When the timer fires (e.g. after a specified interval), the activity is interrupted and the sequence flow going out of the timer boundary event are followed.

A timer boundary event is visualized as a typical boundary event (i.e. circle on the border), with the timer icon on the inside.

A timer boundary event is defined as a regular boundary event. The specific type sub-element is in this case a timerEventDefinition element.

<boundaryEvent id="escalationTimer" cancelActivity="true" attachedToRef="firstLineSupport">
   <timerEventDefinition>
    <timeDuration>PT4H</timeDuration>
  </timerEventDefinition>
</boundaryEvent>

Please refer to timer event definition for details on timer configuration.

In the graphical representation, the line of the circle is dotted as you can see in this example above:

A typical use case is sending an escalation email additionally but not interrupt the normal process flow.

Note: boundary timer events are only fired when the job executor is enabled (i.e. jobExecutorActivate needs to be set to true in the activiti.cfg.xml, since the job executor is disabled by default).

There is a known issue regarding concurrency when using boundary events of any type. Currently, it is not possible to have multiple outgoing sequence flow attached to a boundary event (see issue ACT-47). A solution to this problem is to use one outgoing sequence flow that goes to a parallel gateway.

An intermediate catching error on the boundary of an activity, or boundary error event for short, catches errors that are thrown within the scope of the activity on which it is defined.

Defining a boundary error event makes most sense on an embedded subprocess, or a call activity, as a subprocess creates a scope for all activities inside the subprocess. Errors are thrown by error end events. Such an error will propagate its parent scopes upwards until a scope is found on which a boundary error event is defined that matches the error event definition.

When an error event is caught, the activity on which the boundary event is defined is destroyed, also destroying all current executions within (e.g. concurrent activities, nested subprocesses, etc.). Process execution continues following the outgoing sequence flow of the boundary event.

A boundary error event is visualized as a typical intermediate event (Circle with smaller circle inside) on the boundary, with the error icon inside. The error icon is white, to indicate the catch semantics.

A boundary error event is defined as a typical boundary event:

<boundaryEvent id="catchError" attachedToRef="mySubProcess">
  <errorEventDefinition errorRef="myError"/>
</boundaryEvent>


As with the error end event, the errorRef references an error defined outside the process element:

<error id="myError" errorCode="123" />
...
<process id="myProcess">
...


The errorCode is used to match the errors that are caught:

Following example process shows how an error end event can be used. When the 'Review profitability' user task is completed by stating that not enough information is provided, an error is thrown. When this error is caught on the boundary of the subprocess, all active activities within the 'Review sales lead' subprocess are destroyed (even if 'Review customer rating' was not yet completed), and the 'Provide additional details' user task is created.

This process is shipped as example in the demo setup. The process XML and unit test can be found in the org.activiti.examples.bpmn.event.error package.

An attached intermediate catching signal on the boundary of an activity, or boundary signal event for short, catches signals with the same signal name as the referenced signal definition.

Note: contrary to other events like the boundary error event, a boundary signal event does not only catch signal events thrown from the scope it is attached to. On the contrary, a signal event has global scope (broadcast semantics) meaning that the signal can be thrown from any place, even from a different process instance.

Note: contrary to other events like an error event, a signal is not consumed if it is caught. If you have two active signal boundary events catching the same signal event, both boundary events are triggered, event if they are part of different process instances.

A boundary signal event is visualized as a typical intermediate event (Circle with smaller circle inside) on the boundary, with the signal icon inside. The signal icon is white (unfilled), to indicate the catch semantics.

A boundary signal event is defined as a typical boundary event:

<boundaryEvent id="boundary" attachedToRef="task" cancelActivity="true">
          <signalEventDefinition signalRef="alertSignal"/>
</boundaryEvent>


See section on signal event definitions.

An attached intermediate catching cancel on the boundary of a transaction subprocess, or boundary cancel event for short, is triggered when a transaction is cancelled. When the cancel boundary event is triggered, it first interrupts all executions active in the current scope. Next, it starts compensation of all active compensation boundary events in the scope of the transaction. Compensation is performed synchronously, i.e. the boundary event waits before compensation is completed before leaving the transaction. When compensation is completed, the transaction subprocess is left using the sequence flow(s) running out of the cancel boundary event.

Note: Only a single cancel boundary event is allowed for a transaction subprocess.

Note: If the transaction subprocess hosts nested subprocesses, compensation is only triggered for subprocesses that have completed successfully.

Note: If a cancel boundary event is placed on a transaction subprocess with multi instance characteristics, if one instance triggers cancellation, the boundary event cancels all instances.

A cancel boundary event is visualized as a typical intermediate event (Circle with smaller circle inside) on the boundary, with the cancel icon inside. The cancel icon is white (unfilled), to indicate the catching semantics.

A cancel boundary event is defined as a typical boundary event:

<boundaryEvent id="boundary" attachedToRef="transaction" >
          <cancelEventDefinition />
</boundaryEvent>


Since the cancel boundary event is always interrupting, the cancelActivity attribute is not required.

An attached intermediate catching compensation on the boundary of an activity or compensation boundary event for short, can be used to attach a compensation handler to an activity.

The compensation boundary event must reference a single compensation handler using a directed association.

A compensation boundary event has a different activation policy from other boundary events. Other boundary events like for instance the signal boundary event are activated when the activity they are attached to is started. When the activity is left, they are deactivated and the corresponding event subscription is cancelled. The compensation boundary event is different. The compensation boundary is activated when the activity is attached to completes successfully. At this point, the corresponding subscription to compensation events is created. The subscription is removed either when a compensation event is triggered or when the corresponding process instance ends. From this, it follows:

Note: the compensation boundary event is not supported on embedded subprocesses.

A compensation boundary event is visualized as a typical intermediate event (Circle with smaller circle inside) on the boundary, with the compensation icon inside. The compensation icon is white (unfilled), to indicate the catching semantics. In addition to a compensation boundary event, the following figure shows a compensation handler associated with the boundary event using a unidirectional association:

A compensation boundary event is defined as a typical boundary event:

<boundaryEvent id="compensateBookHotelEvt" attachedToRef="bookHotel" >
          <compensateEventDefinition />
</boundaryEvent>

<association associationDirection="One" id="a1"  sourceRef="compensateBookHotelEvt" targetRef="undoBookHotel" />

<serviceTask id="undoBookHotel" isForCompensation="true" activiti:class="..." />

Since the compensation boundary event is activated after the activity has completed successfully, the cancelActivity attribute is not supported.

A timer intermediate event acts as a stopwatch. When an execution arrives in catching event activity, a timer is started. When the timer fires (e.g. after a specified interval), the sequence flow going out of the timer intermediate event is followed.

A timer intermediate event is visualized as a intermediate catching event, with the timer icon on the inside.

A timer intermediate event is defined as a intermediate catching event. The specific type sub-element is in this case a timerEventDefinition element.

        <intermediateCatchEvent id="timer">
            <timerEventDefinition>
                <timeDuration>PT5M</timeDuration>
            </timerEventDefinition>
        </intermediateCatchEvent>


See timer event definitions for configuration details.

An intermediate catching signal event catches signals with the same signal name as the referenced signal definition.

Note: contrary to other events like an error event, a signal is not consumed if it is caught. If you have two active signal boundary events catching the same signal event, both boundary events are triggered, event if they are part of different process instances.

An intermediate signal catch event is visualized as a typical intermediate event (Circle with smaller circle inside), with the signal icon inside. The signal icon is white (unfilled), to indicate the catch semantics.

A signal intermediate event is defined as a intermediate catching event. The specific type sub-element is in this case a signalEventDefinition element.

<intermediateCatchEvent id="signal">
	<signalEventDefinition signalRef="newCustomerSignal" />
</intermediateCatchEvent>


See section on signal event definitions.

An intermediate throwing signal event throws a signal event for a defined signal.

In activiti, the signal is broadcast to all active handlers (i.e. all catching signal events). Signals can be published synchronous or asynchronous.

An intermediate signal throw event is visualized as a typical intermediate event (Circle with smaller circle inside), with the signal icon inside. The signal icon is black (filled), to indicate the throw semantics.

A signal intermediate event is defined as a intermediate throwing event. The specific type sub-element is in this case a signalEventDefinition element.

<intermediateThrowEvent id="signal">
	<signalEventDefinition signalRef="newCustomerSignal" />
</intermediateThrowEvent>


An asynchronous signal event would look like this:

<intermediateThrowEvent id="signal">
	<signalEventDefinition signalRef="newCustomerSignal" activiti:async="true" />
</intermediateThrowEvent>


See section on signal event definitions.

An intermediate throwing compensation event can be used to trigger compensation.

Triggering compensation: Compensation can either be triggered for a designated activity or for the scope which hosts the compensation event. Compensation is performed through execution of the compensation handler associated with an activity.

Note: If compensation is thrown within a scope which contains a subprocess and the subprocess contains activities with compensation handlers, compensation is only propagated to the subprocess if it has completed successfully when compensation is thrown. If some of the activities nested inside the subprocess have completed and have attached compensation handlers, the compensation handlers are not executed if the subprocess containing these activities is not completed yet. Consider the following example:

In this process we have two concurrent executions, one executing the embedded subprocess and one executing the "charge credit card" activity. Lets assume both executions are started and the first concurrent execution is waiting for a user to complete the "review bookings" task. The second execution performs the "charge credit card" activity and an error is thrown, which causes the "cancel reservations" event to trigger compensation. At this point the parallel subprocess is not yet completed which means that the compensation event is not propagated to the subprocess and thus the "cancel hotel reservation" compensation handler is not executed. If the user task (and thus the embedded subprocess) completes before the "cancel reservations" is performed, compensation is propagated to the embedded subprocess.

Process variables: When compensating an embedded subprocess, the execution used for executing the compensation handlers has access to the local process variables of the subprocess in the state they were in when the subprocess completed execution. To achieve this, a snapshot of the process variables associated with the scope execution (execution created for executing the subprocess) is taken. Form this, a couple of implications follow:

Current limitations:

An intermediate compensation throw event is visualized as a typical intermediate event (Circle with smaller circle inside), with the compensation icon inside. The compensation icon is black (filled), to indicate the throw semantics.

A compensation intermediate event is defined as a intermediate throwing event. The specific type sub-element is in this case a compensateEventDefinition element.

<intermediateThrowEvent id="throwCompensation">
	<compensateEventDefinition />
</intermediateThrowEvent>

In addition, the optional argument activityRef can be used to trigger compensation of a specific scope / activity:

<intermediateThrowEvent id="throwCompensation">
	<compensateEventDefinition activityRef="bookHotel" />
</intermediateThrowEvent>

A sequence flow can have a condition defined on it. When a BPMN 2.0 activity is left, the default behavior is to evaluate the conditions on the outgoing sequence flow. When a condition evaluates to true, that outgoing sequence flow is selected. When multiple sequence flow are selected that way, multiple executions will be generated and the process will be continued in a parallel way.

Note: the above holds for BPMN 2.0 activities (and events), but not for gateways. Gateways will handle sequence flow with conditions in specific ways, depending on the gateway type.

A conditional sequence flow is visualized as a regular sequence flow, with a small diamond at the beginning. The condition expression is shown next to the sequence flow.

A conditional sequence flow is represented in XML as a regular sequence flow, containing a conditionExpression sub-element. Note that for the moment only tFormalExpressions are supported, Omitting the xsi:type="" definition will simply default to this only supported type of expressions.

<sequenceFlow id="flow" sourceRef="theStart" targetRef="theTask">
  <conditionExpression xsi:type="tFormalExpression">
    <![CDATA[${order.price > 100 && order.price < 250}]]>
  </conditionExpression>
</sequenceFlow>

Currently conditionalExpressions can only be used with UEL, detailed info about these can be found in section Expressions. The expression used should resolve to a boolean value, otherwise an exception is thrown while evaluating the condition.

The Activiti distribution contains the following example process using value and method expressions (see org.activiti.examples.bpmn.expression):

All BPMN 2.0 tasks and gateways can have a default sequence flow. This sequence flow is only selected as the outgoing sequence flow for that activity if and only if none of the other sequence flow could be selected. Conditions on a default sequence flow are always ignored.

A default sequence flow is visualized as a regular sequence flow, with a 'slash' marker at the beginning.

A default sequence flow for a certain activity is defined by the default attribute on that activity. The following XML snippet shows for example an exclusive gateway that has as default sequence flow flow 2. Only when conditionA and conditionB both evaluate to false, will it be chosen as outgoing sequence flow for the gateway.

<exclusiveGateway id="exclusiveGw" name="Exclusive Gateway" default="flow2" />
<sequenceFlow id="flow1" sourceRef="exclusiveGw" targetRef="task1">
  <conditionExpression xsi:type="tFormalExpression">${conditionA}</conditionExpression>
</sequenceFlow>
<sequenceFlow id="flow2" sourceRef="exclusiveGw" targetRef="task2"/>
<sequenceFlow id="flow3" sourceRef="exclusiveGw" targetRef="task3">
  <conditionExpression xsi:type="tFormalExpression">${conditionB}</conditionExpression>
</sequenceFlow>


Which corresponds with the following graphical representation:

An exclusive gateway (also called the XOR gateway or more technical the exclusive data-based gateway), is used to model a decision in the process. When the execution arrives at this gateway, all outgoing sequence flow are evaluated in the order in which they are defined. The sequence flow which condition evaluates to true (or which doesn't have a condition set, conceptually having a 'true' defined on the sequence flow) is selected for continuing the process.

Note that the semantics of outgoing sequence flow is different to that of the general case in BPMN 2.0. While in general all sequence flow which condition evaluates to true are selected to continue in a parallel way, only one sequence flow is selected when using the exclusive gateway. In case multiple sequence flow have a condition that evaluates to true, the first one defined in the XML (and only that one!) is selected for continuing the process. If no sequence flow can be selected, an exception will be thrown.

An exclusive gateway is visualized as a typical gateway (i.e. a diamond shape) with an 'X' icon inside, referring to the XOR semantics. Note that a gateway without an icon inside defaults to an exclusive gateway. The BPMN 2.0 specification does not allow mixing the diamond with and without an X in the same process definition.

The XML representation of an exclusive gateway is straight-forward: one line defining the gateway and condition expressions defined on the outgoing sequence flow. See the section on conditional sequence flow to see which options are available for such expressions.

Take for example the following model:

Which is represented in XML as follows:

<exclusiveGateway id="exclusiveGw" name="Exclusive Gateway" />

<sequenceFlow id="flow2" sourceRef="exclusiveGw" targetRef="theTask1">
  <conditionExpression xsi:type="tFormalExpression">${input == 1}</conditionExpression>
</sequenceFlow>

<sequenceFlow id="flow3" sourceRef="exclusiveGw" targetRef="theTask2">
  <conditionExpression xsi:type="tFormalExpression">${input == 2}</conditionExpression>
</sequenceFlow>

<sequenceFlow id="flow4" sourceRef="exclusiveGw" targetRef="theTask3">
  <conditionExpression xsi:type="tFormalExpression">${input == 3}</conditionExpression>
</sequenceFlow>

Gateways can also be used to model concurrency in a process. The most straightforward gateway to introduce concurrency in a process model, is the Parallel Gateway, which allows to fork into multiple paths of execution or join multiple incoming paths of execution.

The functionality of the parallel gateway is based on the incoming and outgoing sequence flow:

Note that a parallel gateway can have both fork and join behavior, if there are multiple incoming and outgoing sequence flow for the same parallel gateway. In that case, the gateway will first join all incoming sequence flow, before splitting into multiple concurrent paths of executions.

An important difference with other gateway types is that the parallel gateway does not evaluate conditions. If conditions are defined on the sequence flow connected with the parallel gateway, they are simply neglected.

A parallel gateway is visualized as a gateway (diamond shape) with the 'plus' symbol inside, referring to the 'AND' semantics.

Defining a parallel gateway needs one line of XML:

<parallelGateway id="myParallelGateway" />

The actual behavior (fork, join or both), is defined by the sequence flow connected to the parallel gateway.

For example, the model above comes down to the following XML:

    <startEvent id="theStart" />
    <sequenceFlow id="flow1" sourceRef="theStart" targetRef="fork" />

    <parallelGateway id="fork" />
    <sequenceFlow sourceRef="fork" targetRef="receivePayment" />
    <sequenceFlow sourceRef="fork" targetRef="shipOrder" />

    <userTask id="receivePayment" name="Receive Payment" />
    <sequenceFlow sourceRef="receivePayment" targetRef="join" />

    <userTask id="shipOrder" name="Ship Order" />
    <sequenceFlow sourceRef="shipOrder" targetRef="join" />

    <parallelGateway id="join" />
    <sequenceFlow sourceRef="join" targetRef="archiveOrder" />

    <userTask id="archiveOrder" name="Archive Order" />
    <sequenceFlow sourceRef="archiveOrder" targetRef="theEnd" />

    <endEvent id="theEnd" />

In the above example, after the process is started, two tasks will be created:

ProcessInstance pi = runtimeService.startProcessInstanceByKey("forkJoin");
TaskQuery query = taskService.createTaskQuery()
                         .processInstanceId(pi.getId())
                         .orderByTaskName()
                         .asc();

List<Task> tasks = query.list();
assertEquals(2, tasks.size());

Task task1 = tasks.get(0);
assertEquals("Receive Payment", task1.getName());
Task task2 = tasks.get(1);
assertEquals("Ship Order", task2.getName());

When these two tasks are completed, the second parallel gateway will join the two executions and since there is only one outgoing sequence flow, no concurrent paths of execution will be created, and only the Archive Order task will be active.

Note that a parallel gateway does not need to be 'balanced' (i.e. a matching number of incoming/outgoing sequence flow for corresponding parallel gateways). A parallel gateway will simply wait for all incoming sequence flow and create a concurrent path of execution for each outgoing sequence flow, not influenced by other constructs in the process model. So, the following process is legal in BPMN 2.0:

The Inclusive Gateway can be seen as a combination of an exclusive and a parallel gateway. Like an exclusive gateway you can define conditions on outgoing sequence flows and the inclusive gateway will evaluate them. But the main difference is that the inclusive gateway can take more than one sequence flow, like the parallel gateway.

The functionality of the inclusive gateway is based on the incoming and outgoing sequence flow:

Note that an inclusive gateway can have both fork and join behavior, if there are multiple incoming and outgoing sequence flow for the same inclusive gateway. In that case, the gateway will first join all incoming sequence flows that have a process token, before splitting into multiple concurrent paths of executions for the outgoing sequence flows that have a condition that evaluates to true.

A parallel gateway is visualized as a gateway (diamond shape) with the 'circle' symbol inside.

Defining an inclusive gateway needs one line of XML:

<inclusiveGateway id="myInclusiveGateway" />

The actual behavior (fork, join or both), is defined by the sequence flows connected to the inclusive gateway.

For example, the model above comes down to the following XML:

    <startEvent id="theStart" />
    <sequenceFlow id="flow1" sourceRef="theStart" targetRef="fork" />

    <inclusiveGateway id="fork" />
    <sequenceFlow sourceRef="fork" targetRef="receivePayment" >
    <conditionExpression xsi:type="tFormalExpression">${paymentReceived == false}</conditionExpression>
    </sequenceFlow>
    <sequenceFlow sourceRef="fork" targetRef="shipOrder" >
    <conditionExpression xsi:type="tFormalExpression">${shipOrder == true}</conditionExpression>
    </sequenceFlow>

    <userTask id="receivePayment" name="Receive Payment" />
    <sequenceFlow sourceRef="receivePayment" targetRef="join" />

    <userTask id="shipOrder" name="Ship Order" />
    <sequenceFlow sourceRef="shipOrder" targetRef="join" />

    <inclusiveGateway id="join" />
    <sequenceFlow sourceRef="join" targetRef="archiveOrder" />

    <userTask id="archiveOrder" name="Archive Order" />
    <sequenceFlow sourceRef="archiveOrder" targetRef="theEnd" />

    <endEvent id="theEnd" />

In the above example, after the process is started, two tasks will be created if the process variables paymentReceived == false and shipOrder == true. In case only one of these process variables equals to true only one task will be created. If no condition evaluates to true and exception is thrown. This can be prevented by specifying a default outgoing sequence flow. In the following example one task will be created, the ship order task:

HashMap<String, Object> variableMap = new HashMap<String, Object>();
          variableMap.put("receivedPayment", true);
          variableMap.put("shipOrder", true);
          ProcessInstance pi = runtimeService.startProcessInstanceByKey("forkJoin");
TaskQuery query = taskService.createTaskQuery()
                         .processInstanceId(pi.getId())
                         .orderByTaskName()
                         .asc();

List<Task> tasks = query.list();
assertEquals(1, tasks.size());

Task task = tasks.get(0);
assertEquals("Ship Order", task.getName());

When this task is completed, the second inclusive gateway will join the two executions and since there is only one outgoing sequence flow, no concurrent paths of execution will be created, and only the Archive Order task will be active.

Note that an inclusive gateway does not need to be 'balanced' (i.e. a matching number of incoming/outgoing sequence flow for corresponding inclusive gateways). An inclusive gateway will simply wait for all incoming sequence flow and create a concurrent path of execution for each outgoing sequence flow, not influenced by other constructs in the process model.

The event based gateway allows to take a decision based on events. Each outgoing sequenceflow of the gateway needs to be connected to an intermediate catching event. When process execution reaches the event based gateway, the gateway acts like a wait state: execution is suspended. In addition, for each outgoing sequence flow, an event subscription is created.

Note the sequence flows running out of an event based gateway are different from ordinary sequence flows. These sequence flows are never actually "executed". On the contrary, they allow the process engine to determine which events an execution arriving at an event based gateway needs to subscribe to. The following restrictions apply:

An event based gateway gateway is visualized as a typical gateway (i.e. a diamond shape) with a special icon inside.

The xml element used to define an event based gateway is eventBasedGateway.

The following process is an example of a process with an event based gateway. When the execution arrives at the event based gateway, process execution is suspended. In addition, the process instance subscribes to the alert signal event and created a timer which fires after 10 minutes. This effectively causes the process engine to wait for ten minutes for a signal event. If the signal occurs within 10 minutes, the timer is cancelled and execution continues after the signal. If the signal is not fired, execution continues after the timer and the signal subscription is cancelled.


<definitions id="definitions"
	xmlns="http://www.omg.org/spec/BPMN/20100524/MODEL"
	xmlns:activiti="http://activiti.org/bpmn"
	targetNamespace="Examples">

	<signal id="alertSignal" name="alert" />

	<process id="catchSignal">

		<startEvent id="start" />

		<sequenceFlow sourceRef="start" targetRef="gw1" />

		<eventBasedGateway id="gw1" />

		<sequenceFlow sourceRef="gw1" targetRef="signalEvent" />
		<sequenceFlow sourceRef="gw1" targetRef="timerEvent" />

		<intermediateCatchEvent id="signalEvent" name="Alert">
			<signalEventDefinition signalRef="alertSignal" />
		</intermediateCatchEvent>

		<intermediateCatchEvent id="timerEvent" name="Alert">
			<timerEventDefinition>
				<timeDuration>PT10M</timeDuration>
			</timerEventDefinition>
		</intermediateCatchEvent>

		<sequenceFlow sourceRef="timerEvent" targetRef="exGw1" />
		<sequenceFlow sourceRef="signalEvent" targetRef="task" />

		<userTask id="task" name="Handle alert"/>

		<exclusiveGateway id="exGw1" />

		<sequenceFlow sourceRef="task" targetRef="exGw1" />
		<sequenceFlow sourceRef="exGw1" targetRef="end" />

		<endEvent id="end" />
</process>
</definitions>

A 'user task' is used to model work that needs to be done by a human actor. When the process execution arrives at such a user task, a new task is created in the task list of the user(s) or group(s) assigned to that task.

A user task is visualized as a typical task (rounded rectangle), with a small user icon in the left upper corner.

A user task is defined in XML as follows. The id attribute is required, the name attribute is optional.

<userTask id="theTask" name="Important task" />


A user task can have also a description. In fact any BPMN 2.0 element can have a description. A description is defined by adding the documentation element.

<userTask id="theTask" name="Schedule meeting" >
  <documentation>
	  Schedule an engineering meeting for next week with the new hire.
  </documentation>

The description text can be retrieved from the task in the standard Java way:

task.getDescription()

Each task has a field, indicating the due date of that task. The Query API can be used to query for task that are due on, before or after a certain date.

There is an activity extension which allows you to specify an expression in your task-definition to set the initial due date of a task when it is created. The expression should always resolve to a java.util.Date or null. For example, you could use a date that was entered in a previous form in the process or calculated in a previous Service Task.

<userTask id="theTask" name="Important task" activiti:dueDate="${dateVariable}"/>

A user task can be directly assigned to a user. This is done by defining a humanPerformer sub element. Such a humanPerformer definition needs a resourceAssignmentExpression that actually defines the user. Currently, only formalExpressions are supported.

<process ... >

  ...

  <userTask id='theTask' name='important task' >
    <humanPerformer>
      <resourceAssignmentExpression>
        <formalExpression>kermit</formalExpression>
      </resourceAssignmentExpression>
    </humanPerformer>
  </userTask>

Only one user can be assigned as human performer to the task. In Activiti terminology, this user is called the assignee. Task that have an assignee are not visible in the task lists of other people, and are found in the so-called personal task list of the assignee.

Tasks directly assigned to users can be retrieved through the TaskService as follows:

List<Task> tasks = taskService.createTaskQuery().taskAssignee("kermit").list();

Tasks can also be put in the so-called candidate task list of people. In that case, the potentialOwner construct must be used. The usage is similar to the humanPerformer construct. Do note that it is required to define for each element in the formal expression to specify if it is a user or a group (the engine cannot guess this).

<process ... >

  ...

  <userTask id='theTask' name='important task' >
    <potentialOwner>
      <resourceAssignmentExpression>
        <formalExpression>user(kermit), group(management)</formalExpression>
      </resourceAssignmentExpression>
    </potentialOwner>
  </userTask>

Tasks defines with the potential owner construct, can be retrieved as follows (or a similar TaskQuery usage as for the tasks with an assignee):

 List<Task> tasks = taskService.createTaskQuery().taskCandidateUser("kermit");

This will retrieve all tasks where kermit is a candidate user, i.e. the formal expression contains user(kermit). This will also retrieve all tasks that are assigned to a group where kermit is a member of (e.g. group(management), if kermit is a member of that group and the Activiti identity component is used). The groups of the user are resolved at runtime and these can be managed through the IdentityService.

If no specifics are given whether the given text string is a user or group, the engine defaults to group. So the following would be the same as when group(accountancy) was declared.

<formalExpression>accountancy</formalExpression>

It is clear that user and group assignments are quite cumbersome for use cases where the assignment is not complex. To avoid these complexities, custom extensions on the user task are possible.

In case the previous approaches are not sufficient, it is possible to delegate to custom assignment logic using a task listener on the create event:

<userTask id="task1" name="My task" >
  <extensionElements>
    <activiti:taskListener event="create" class="org.activiti.MyAssignmentHandler" />
  </extensionElements>
</userTask>

The DelegateTask that is passed to the TaskListener implementation, allows to set the assignee and candidate-users/groups:

public class MyAssignmentHandler implements TaskListener {

  public void notify(DelegateTask delegateTask) {
    // Execute custom identity lookups here

    // and then for example call following methods:
    delegateTask.setAssignee("kermit");
    delegateTask.addCandidateUser("fozzie");
    delegateTask.addCandidateGroup("management");
    ...
  }

}

When using Spring it is possible to use the custom assignment attributes as described in the section above, and delegate to a Spring bean using a task listener with an expression that listens to task create events. In the following example, the assignee will be set by calling the findManagerOfEmployee on the ldapService Spring bean. The emp parameter that is passed, is a process variable>.

<userTask id="task" name="My Task" activiti:assignee="${ldapService.findManagerForEmployee(emp)}"/>

This also works similar for candidate users and groups:

<userTask id="task" name="My Task" activiti:candidateUsers="${ldapService.findAllSales()}"/>

Note that this will only work if the return type of the invoked methods is String or Collection<String> (for candidate users and groups):


public class FakeLdapService {

  public String findManagerForEmployee(String employee) {
    return "Kermit The Frog";
  }

  public List<String> findAllSales() {
    return Arrays.asList("kermit", "gonzo", "fozzie");
  }

}

A script task is an automatic activity. When a process execution arrives at the script task, the corresponding script is executed.

A script task is visualized as a typical BPMN 2.0 task (rounded rectangle), with a small 'script' icon in the top-left corner of the rectangle.

A script task is defined by specifying the script and the scriptFormat.

<scriptTask id="theScriptTask" name="Execute script" scriptFormat="groovy">
  <script>
    sum = 0
    for ( i in inputArray ) {
      sum += i
    }
  </script>
</scriptTask>

The value of the scriptFormat attribute must be a name that is compatible with the JSR-223 (scripting for the Java platform). The Groovy jar is shipped by default with the Activiti distribution. If you want to use another (JSR-223 compatible) scripting engine, it is sufficient to add the corresponding jar to the classpath and use the appropriate name.

All process variables that are accessible through the execution that arrives in the script task, can be used within the script. In the example, the script variable 'inputArray' is in fact a process variable (an array of integers).

<script>
    sum = 0
    for ( i in inputArray ) {
      sum += i
    }
</script>

It's also possible to set process variables in a script, simply by using an assignment statement. In the example above, the 'sum' variable will be stored as a process variable after the script task has been executed. To avoid this behavior, script-local variables can be used. In Groovy, the keyword 'def' must then be used: 'def sum = 0'. In that case, no process variable will be stored.

An alternative is to set variables through the current execution, which is available as a reserved variable called 'execution'.

<script>
    def scriptVar = "test123"
    execution.setVariable("myVar", scriptVar)
</script>

Note: the following names are reserved and cannot be used as variable names: out, out:print, lang:import, context, elcontext.

The return value of a script task can be assigned to an already existing or to a new process variable by specifying the process variable name as a literal value for the 'activiti:resultVariable' attribute of a script task definition. Any existing value for a specific process variable will be overwritten by the result value of the script execution. When not specifying a result variable name, the script result value gets ignored.

<scriptTask id="theScriptTask" name="Execute script" scriptFormat="juel" activiti:resultVariable="myVar">
  <script>#{echo}</script>
</scriptTask>

In the above example, the result of the script execution (the value of the resolved expression '#{echo}') is set to the process variable named 'myVar' after the script completes.

A Java service task is used to invoke an external Java class.

A service task is visualized as a rounded rectangle with a small gear icon in the top-left corner.

There are 4 ways of declaring how to invoke Java logic:

To specify a class that is called during process execution, the fully qualified classname needs to be provided by the 'activiti:class' attribute.

<serviceTask id="javaService"
             name="My Java Service Task"
             activiti:class="org.activiti.MyJavaDelegate" />

See the implementation section for more details on how to use such a class.

It is also possible to use an expression that resolves to an object. This object must follow the same rules as objects that are created when the activiti:class attribute is used (see further).

 <serviceTask id="serviceTask" activiti:delegateExpression="${delegateExpressionBean}" />

Here, the delegateExpressionBean is a bean that implements the JavaDelegate interface, defined in for example the Spring container.

To specify a UEL method expression that should be evaluated, use attribute activiti:expression.

<serviceTask id="javaService"
             name="My Java Service Task"
             activiti:expression="#{printer.printMessage()}" />

Method printMessage (without parameters) will be called on the named object called printer.

It's also possible to pass parameters with an method used in the expression.

<serviceTask id="javaService"
             name="My Java Service Task"
             activiti:expression="#{printer.printMessage(execution, myVar)}" />

Method printMessage will be called on the object named printer. The first parameter passed is the DelegateExecution, which is available in the expression context by default available as execution. The second parameter passed, is the value of the variable with name myVar in the current execution.

To specify a UEL value expression that should be evaluated, use attribute activiti:expression.

<serviceTask id="javaService"
             name="My Java Service Task"
             activiti:expression="#{split.ready}" />

The getter method of property ready, getReady (without parameters), will be called on the named bean called split. The named objects are resolved in the execution's process variables and (if applicable) in the Spring context.

To implement a class that can be called during process execution, this class needs to implement the org.activiti.engine.delegate.JavaDelegate interface and provide the required logic in the execute method. When process execution arrives at this particular step, it will execute this logic defined in that method and leave the activity in the default BPMN 2.0 way.

Let's create for example a Java class that can be used to change a process variable String to uppercase. This class needs to implement the org.activiti.engine.delegate.JavaDelegate interface, which requires us to implement the execute(DelegateExecution) method. It's this operation that will be called by the engine and which needs to contain the business logic. Process instance information such as process variables and other can be accessed and manipulated through the DelegateExecution interface (click on the link for a detailed Javadoc of its operations).

public class ToUppercase implements JavaDelegate {

  public void execute(DelegateExecution execution) throws Exception {
    String var = (String) execution.getVariable("input");
    var = var.toUpperCase();
    execution.setVariable("input", var);
  }

}

Note: there will be only one instance of that Java class created for the serviceTask it is defined on. All process-instances share the same class instance that will be used to call execute(DelegateExecution). This means that the class must not use any member variables and must be thread-safe, since it can be executed simultaneously from different threads. This also influences the way Field injection is handled.

The classes that are referenced in the process definition (i.e. by using activiti:class) are NOT instantiated during deployment. Only when a process execution arrives for the first time at the point in the process where the class is used, an instance of that class will be created. If the class cannot be found, an ActivitiException will be thrown. The reasoning for this is that the environment (and more specifically the classpath) when you are deploying is often different from the actual runtime environment. For example when using ant or the business archive upload in Activiti Explorer to deploy processes, the classpath does not contain the referenced classes.

[INTERNAL: non-public implementation classes] It is also possible to provide a class that implements the org.activiti.engine.impl.pvm.delegate.ActivityBehavior interface. Implementations have then access to the more powerful ActivityExecution that for example also allows to influence the control flow of the process. Note however that this is not a very good practice, and should be avoided as much as possible. So, it is advised to use the ActivityBehavior interface only for advanced use cases and if you know exactly what you're doing.

It's possible to inject values into the fields of the delegated classes. The following types of injection are supported:

If available, the value is injected through a public setter method on your delegated class, following the Java Bean naming conventions (e.g. field fistName has setter setFirstName(...)). If no setter is available for that field, the value of private member will be set on the delegate. SecurityManagers in some environments don't allow modifying private fields, so it's safer to expose a public setter-method for the fields you want to have injected. Regardless of the type of value declared in the process-definition, the type of the setter/private field on the injection target should always be org.activiti.engine.delegate.Expression.

The following code snippet shows how to inject a constant value into a field. Field injection is supported when using the 'class' attribute. Note that we need to declare a 'extensionElements' XML element before the actual field injection declarations, which is a requirement of the BPMN 2.0 XML Schema.

<serviceTask id="javaService"
    name="Java service invocation"
    activiti:class="org.activiti.examples.bpmn.servicetask.ToUpperCaseFieldInjected">
    <extensionElements>
      <activiti:field name="text" stringValue="Hello World" />
  </extensionElements>
</serviceTask>


The class ToUpperCaseFieldInjected has a field text which is of type org.activiti.engine.delegate.Expression. When calling text.getValue(execution), the configured string value Hello World will be returned.

Alternatively, for longs texts (e.g. an inline e-mail) the 'activiti:string' sub element can be used:

<serviceTask id="javaService"
    name="Java service invocation"
    activiti:class="org.activiti.examples.bpmn.servicetask.ToUpperCaseFieldInjected">
  <extensionElements>
    <activiti:field name="text">
        <activiti:string>
          Hello World
      </activiti:string>
    </activiti:field>
  </extensionElements>
</serviceTask>


To inject values that are dynamically resolved at runtime, expressions can be used. Those expressions can use process variables, or Spring defined beans (if Spring is used). As noted in Service Task Implementation, an instance of the Java class is shared among all process-instances in a service task. To have dynamic injection of values in fields, you can inject value and method expressions in a org.activiti.engine.delegate.Expression which can be evaluated/invoked using the DelegateExecution passed in the execute method.

<serviceTask id="javaService" name="Java service invocation"
  activiti:class="org.activiti.examples.bpmn.servicetask.ReverseStringsFieldInjected">

  <extensionElements>
    <activiti:field name="text1">
      <activiti:expression>${genderBean.getGenderString(gender)}</activiti:expression>
    </activiti:field>
    <activiti:field name="text2">
       <activiti:expression>Hello ${gender == 'male' ? 'Mr.' : 'Mrs.'} ${name}</activiti:expression>
    </activiti:field>
  </ extensionElements>
</ serviceTask>

The example class below uses the injected expressions and resolves them using the current DelegateExecution. Full code and test can be found in org.activiti.examples.bpmn.servicetask.JavaServiceTaskTest.testExpressionFieldInjection

public class ReverseStringsFieldInjected implements JavaDelegate {

  private Expression text1;
  private Expression text2;

  public void execute(DelegateExecution execution) {
    String value1 = (String) text1.getValue(execution);
    execution.setVariable("var1", new StringBuffer(value1).reverse().toString());

    String value2 = (String) text2.getValue(execution);
    execution.setVariable("var2", new StringBuffer(value2).reverse().toString());
  }
}

Alternatively, you can also set the expressions as an attribute instead of a child-element, to make the XML less verbose.

<activiti:field name="text1" expression="${genderBean.getGenderString(gender)}" />
<activiti:field name="text1" expression="Hello ${gender == 'male' ? 'Mr.' : 'Mrs.'} ${name}" />

Since the Java class instance is reused, the injection only happens once, when the serviceTask is called the first time. When the fields are altered by your code, the values won't be re-injected so you should treat them as immutable and don't make any changes to them.

The return value of a service execution (for service task using expression only) can be assigned to an already existing or to a new process variable by specifying the process variable name as a literal value for the 'activiti:resultVariable' attribute of a service task definition. Any existing value for a specific process variable will be overwritten by the result value of the service execution. When not specifying a result variable name, the service execution result value gets ignored.

<serviceTask id="aMethodExpressionServiceTask"
    activiti:expression="#{myService.doSomething()}"
    activiti:resultVariable="myVar" />

In the example above, the result of the service execution (the return value of the 'doSomething()' method invocation on an object that is made available under the name 'myService' either in the process variables or as a Spring bean) is set to the process variable named 'myVar' after the service execution completes.

When custom logic is executed, it is often required to catch certain business exceptions and handle them inside the surrounding process. Activiti provides different options to do that.

public class ThrowBpmnErrorDelegate implements JavaDelegate {

  public void execute(DelegateExecution execution) throws Exception {
    try {
      executeBusinessLogic();
    } catch (BusinessExeption e) {
      throw new BpmnError("BusinessExeptionOccured");
    }
  }

}

<serviceTask id="javaService"
  name="Java service invocation"
  activiti:class="org.activiti.ThrowsExceptionBehavior">
</serviceTask>

<sequenceFlow id="no-exception" sourceRef="javaService" targetRef="theEnd" />
<sequenceFlow id="exception" sourceRef="javaService" targetRef="fixException" />

public class ThrowsExceptionBehavior implements ActivityBehavior {

  public void execute(ActivityExecution execution) throws Exception {
    String var = (String) execution.getVariable("var");

    PvmTransition transition = null;
    try {
      executeLogic(var);
      transition = execution.getActivity().findOutgoingTransition("no-exception");
    } catch (Exception e) {
      transition = execution.getActivity().findOutgoingTransition("exception");
    }
    execution.take(transition);
  }

}

A WebService task is used to synchronously invoke an external web service.

A WebService task is visualized the same as a Java service task.

To use a WebService we need to import its operations and complex types. This can be done automatically by using the import tag pointing to the WSDL of the WebService:

<import importType="http://schemas.xmlsoap.org/wsdl/"
	location="http://localhost:63081/counter?wsdl"
	namespace="http://webservice.activiti.org/" />

The previous declaration tells Activiti to import the definitions but it doesn't create the item definitions and messages for you. Let's suppose we want to invoke a specific method called 'prettyPrint', therefore we will need to create the corresponding message and item definitions for the request and response messages:

<message id="prettyPrintCountRequestMessage" itemRef="tns:prettyPrintCountRequestItem" />
<message id="prettyPrintCountResponseMessage" itemRef="tns:prettyPrintCountResponseItem" />

<itemDefinition id="prettyPrintCountRequestItem" structureRef="counter:prettyPrintCount" />
<itemDefinition id="prettyPrintCountResponseItem" structureRef="counter:prettyPrintCountResponse" />

Before declaring the service task, we have to define the BPMN interfaces and operations that actually reference the WebService ones. Basically, we define and 'interface' and the required 'operation's'. For each operation we reuse the previous defined message for in and out. For example, the following declaration defines the 'counter' interface and the 'prettyPrintCountOperation' operation:

<interface name="Counter Interface" implementationRef="counter:Counter">
	<operation id="prettyPrintCountOperation" name="prettyPrintCount Operation"
			implementationRef="counter:prettyPrintCount">
		<inMessageRef>tns:prettyPrintCountRequestMessage</inMessageRef>
		<outMessageRef>tns:prettyPrintCountResponseMessage</outMessageRef>
	</operation>
</interface>

Then we can declare a WebService task by using the ##WebService implementation and a reference to the WebService operation.

<serviceTask id="webService"
	name="Web service invocation"
	implementation="##WebService"
	operationRef="tns:prettyPrintCountOperation">

Unless we are using the simplistic approach for data input and output associations (See below), each WebService task needs to declare an IO Specification which states which are the inputs and outputs of the task. The approach is pretty straightforward and BPMN 2.0 complaint, for our prettyPrint example we define the input and output sets according to the previously declared item definitions:

<ioSpecification>
	<dataInput itemSubjectRef="tns:prettyPrintCountRequestItem" id="dataInputOfServiceTask" />
	<dataOutput itemSubjectRef="tns:prettyPrintCountResponseItem" id="dataOutputOfServiceTask" />
	<inputSet>
		<dataInputRefs>dataInputOfServiceTask</dataInputRefs>
	</inputSet>
	<outputSet>
		<dataOutputRefs>dataOutputOfServiceTask</dataOutputRefs>
	</outputSet>
</ioSpecification>

There are 2 ways of specifying data input associations:

To specify the data input association using expressions we need to define the source and target items and specify the corresponding assignments between the fields of each item. In the following example we assign prefix and suffix fields of the items:

<dataInputAssociation>
	<sourceRef>dataInputOfProcess</sourceRef>
	<targetRef>dataInputOfServiceTask</targetRef>
	<assignment>
		<from>${dataInputOfProcess.prefix}</from>
		<to>${dataInputOfServiceTask.prefix}</to>
	</assignment>
	<assignment>
		<from>${dataInputOfProcess.suffix}</from>
		<to>${dataInputOfServiceTask.suffix}</to>
	</assignment>
</dataInputAssociation>

On the other hand we can use the simplistic approach which is much more simple. The 'sourceRef' element is an Activiti variable name and the 'targetRef' element is a property of the item definition. In the following example we assign to the 'prefix' field the value of the variable 'PrefixVariable' and to the 'suffix' field the value of the variable 'SuffixVariable'.

<dataInputAssociation>
	<sourceRef>PrefixVariable</sourceRef>
	<targetRef>prefix</targetRef>
</dataInputAssociation>
<dataInputAssociation>
	<sourceRef>SuffixVariable</sourceRef>
	<targetRef>suffix</targetRef>
</dataInputAssociation>

There are 2 ways of specifying data out associations:

To specify the data out association using expressions we need to define the target variable and the source expression. The approach is pretty straightforward and similar data input associations:

<dataOutputAssociation>
	<targetRef>dataOutputOfProcess</targetRef>
	<transformation>${dataOutputOfServiceTask.prettyPrint}</transformation>
</dataOutputAssociation>

On the other hand we can use the simplistic approach which is much more simple. The 'sourceRef' element is a property of the item definition and the 'targetRef' element is an Activiti variable name. The approach is pretty straightforward and similar data input associations:

<dataOutputAssociation>
	<sourceRef>prettyPrint</sourceRef>
	<targetRef>OutputVariable</targetRef>
</dataOutputAssociation>

A Business Rule task is used to synchronously execute one or more rules. Activiti uses Drools Expert, the Drools rule engine to execute business rules. Currently, the .drl files containing the business rules have to be deployed together with the process definition that defines a business rule task to execute those rules. This means that all .drl files that are used in a process have to be packaged in the process BAR file like for example the task forms. For more information about creating business rules for Drools Expert please refer to the Drools documentation at JBoss Drools

A Business Rule task is visualized the with a table icon.

To execute one or more business rules that are deployed in the same BAR file as the process definition, we need to define the input and result variables. For the input variable definition a list of process variables can be defined separated by a comma. The output variable definition can only contain one variable name that will be used to store the output objects of the executed business rules in a process variable. Note that the result variable will contain a List of objects. If no result variable name is specified by default org.activiti.engine.rules.OUTPUT is used.

The following business rule task executes all business rules deployed with the process definition:

<process id="simpleBusinessRuleProcess">

  <startEvent id="theStart" />
  <sequenceFlow sourceRef="theStart" targetRef="businessRuleTask" />

  <businessRuleTask id="businessRuleTask" activiti:ruleVariablesInput="${order}"
      activiti:resultVariable="rulesOutput" />

  <sequenceFlow sourceRef="businessRuleTask" targetRef="theEnd" />

  <endEvent id="theEnd" />

</process>


The business rule task can also be configured to execute only a defined set of rules from the deployed .drl files. A list of rule names separated by a comma must be specified for this.

<businessRuleTask id="businessRuleTask" activiti:ruleVariablesInput="${order}"
      activiti:rules="rule1, rule2" />


In this case only rule1 and rule2 are executed.

You can also define a list of rules that should be excluded from execution.

<businessRuleTask id="businessRuleTask" activiti:ruleVariablesInput="${order}"
      activiti:rules="rule1, rule2" exclude="true" />


In this case all rules deployed in the same BAR file as the process definition will be executed, except for rule1 and rule2.

The Activiti engine sends e-mails trough an external mail server with SMTP capabilities. To actually send e-mails, the engine needs to know how to reach the mail server. Following properties can be set in the activiti.cfg.xml configuration file:

The Email task is implemented as a dedicated Service Task and is defined by setting 'mail' for the type of the service task.

<serviceTask id="sendMail" activiti:type="mail">


The Email task is configured by field injection. All the values for these properties can contain EL expression, which are resolved at runtime during process execution. Following properties can be set:

The following XML snippet shows an example of using the Email Task.

<serviceTask id="sendMail" activiti:type="mail">
  <extensionElements>
    <activiti:field name="from" stringValue="order-shipping@thecompany.com" />
    <activiti:field name="to" expression="${recipient}" />
    <activiti:field name="subject" expression="Your order ${orderId} has been shipped" />
    <activiti:field name="html">
      <activiti:expression>
        <![CDATA[
          <html>
            <body>
              Hello ${male ? 'Mr.' : 'Mrs.' } ${recipientName},<br/><br/>

              As of ${now}, your order has been <b>processed and shipped</b>.<br/><br/>

              Kind regards,<br/>

              TheCompany.
            </body>
          </html>
        ]]>
      </activiti:expression>
    </activiti:field>
  </extensionElements>
</serviceTask>


with the following result:

The Mule task is implemented as a dedicated Service Task and is defined by setting 'mule' for the type of the service task.

<serviceTask id="sendMule" activiti:type="mule">


The Mule task is configured by field injection. All the values for these properties can contain EL expression, which are resolved at runtime during process execution. Following properties can be set:

The following XML snippet shows an example of using the Mule Task.

      <extensionElements>
        <activiti:field name="endpointUrl">
          <activiti:string>vm://in</activiti:string>
        </activiti:field>
        <activiti:field name="language">
          <activiti:string>juel</activiti:string>
        </activiti:field>
        <activiti:field name="payloadExpression">
          <activiti:string>"hi"</activiti:string>
        </activiti:field>
        <activiti:field name="resultVariable">
          <activiti:string>theVariable</activiti:string>
        </activiti:field>
      </extensionElements>


A Manual Task defines a task that is external to the BPM engine. It is used to model work that is done by somebody, which the engine does not need to know of, nor is there a system or UI interface. For the engine, a manual task is handled as a pass-through activity, automatically continuing the process from the moment process execution arrives into it.

A manual task is visualized as a rounded rectangle, with a little 'hand' icon in the upper left corner

<manualTask id="myManualTask" name="Call client for more information" />

A receive task is a simple task that waits for the arrival of a certain message. Currently, we have only implemented Java semantics for this task. When process execution arrives at a receive task, the process state is committed to the persistence store. This means that the process will stay in this wait state, until a specific message is received by the engine, which triggers the continuation of the process past the receive task.

A receive task is visualized as a task (rounded rectangle) with a message icon in the top left corner. The message is white (a black message icon would have send semantics)

<receiveTask id="waitState" name="wait" />

To continue a process instance that is currently waiting at such a receive task, the runtimeService.signal(executionId) must be called using the id of the execution that arrived in the receive task. The following code snippet shows how this works in practice:

ProcessInstance pi = runtimeService.startProcessInstanceByKey("receiveTask");
Execution execution = runtimeService.createExecutionQuery()
  .processInstanceId(pi.getId())
  .activityId("wait")
  .singleResult();
assertNotNull(execution);

runtimeService.signal(execution.getId());


The shell task allows to run shell scripts and commands. Note that the Shell task is not an 'official' task of BPMN 2.0 spec (and it does not have a dedicated icon as a consequence).

The shell task is implemented as a dedicated Service Task and is defined by setting 'shell' for the type of the service task.

<serviceTask id="shellEcho" activiti:type="shell">


The Shell task is configured by field injection. All the values for these properties can contain EL expression, which are resolved at runtime during process execution. Following properties could be set:

The following XML snippet shows an example of using the shell Task. It runs shell script "cmd /c echo EchoTest", waits for it to be terminated and puts the result in resultVar

<serviceTask id="shellEcho" activiti:type="shell" >
  <extensionElements>
    <activiti:field name="command" stringValue="cmd" />
    <activiti:field name="arg1" stringValue="/c" />
    <activiti:field name="arg2" stringValue="echo" />
    <activiti:field name="arg3" stringValue="EchoTest" />
    <activiti:field name="wait" stringValue="true" />
    <activiti:field name="outputVariable" stringValue="resultVar" />
  </extensionElements>
</serviceTask>


When using an execution listener that is configured with the class attribute, field injection can be applied. This is exactly the same mechanism as used Service task field injection, which contains an overview of the possibilities provided by field injection.

The fragment below shows a simple example process with an execution listener with fields injected.

 <process id="executionListenersProcess">
    <extensionElements>
      <activiti:executionListener class="org.activiti.examples.bpmn.executionListener.ExampleFieldInjectedExecutionListener" event="start">
        <activiti:field name="fixedValue" stringValue="Yes, I am " />
        <activiti:field name="dynamicValue" expression="${myVar}" />
      </activiti:executionListener>
    </extensionElements>

    <startEvent id="theStart" />
    <sequenceFlow sourceRef="theStart" targetRef="firstTask" />

    <userTask id="firstTask" />
    <sequenceFlow sourceRef="firstTask" targetRef="theEnd" />

    <endEvent id="theEnd" />
  </process>


public class ExampleFieldInjectedExecutionListener implements ExecutionListener {

  private Expression fixedValue;

  private Expression dynamicValue;

  public void notify(ExecutionListenerExecution execution) throws Exception {
    execution.setVariable("var", fixedValue.getValue(execution).toString() + dynamicValue.getValue(execution).toString());
  }
}


The class ExampleFieldInjectedExecutionListener concatenates the 2 injected fields (one fixed an the other dynamic) and stores this in the process variable 'var'.

@Deployment(resources = {"org/activiti/examples/bpmn/executionListener/ExecutionListenersFieldInjectionProcess.bpmn20.xml"})
public void testExecutionListenerFieldInjection() {
  Map<String, Object> variables = new HashMap<String, Object>();
  variables.put("myVar", "listening!");

  ProcessInstance processInstance = runtimeService.startProcessInstanceByKey("executionListenersProcess", variables);

  Object varSetByListener = runtimeService.getVariable(processInstance.getId(), "var");
  assertNotNull(varSetByListener);
  assertTrue(varSetByListener instanceof String);

  // Result is a concatenation of fixed injected field and injected expression
  assertEquals("Yes, I am listening!", varSetByListener);
}


A multi-instance activity is a way of defining repetition for a certain step in a business process. In programming concepts, a multi-instance matches the for each construct: it allows to execute a certain step or even a complete subprocess for each item in a given collection, sequentially or in parallel.

A multi-instance is a regular activity that has extra properties defined (so-called 'multi-instance characteristics'') which will cause the activity to be executed multiple times at runtime. Following activities can become a multi-instance activity:

A gateway or event can not become multi-instance.

As required by the spec, each parent execution of the created executions for each instance will have following variables:

These values can be retrieved by calling the execution.getVariable(x) method.

Additionally, each of the created executions will have an execution-local variable (i.e. not visible for the other executions, and not stored on process instance level) :

If an activity is multi-instance, this is indicated by three short lines at the bottom of that activity. Three vertical lines indicates that the instances will be executed in parallel, while three horizontal lines indicate sequential execution.

To make an activity multi-instance, the activity xml element must have a multiInstanceLoopCharacteristics child element.

<multiInstanceLoopCharacteristics isSequential="false|true">
 ...
</multiInstanceLoopCharacteristics>

The isSequential attribute indicates if the instances of that activity are executed sequentially or parallel.

The number of instances are calculated once, when entering the activity. There are a few ways of configuring this. On way is directly specifying a number, by using the loopCardinality child element.

<multiInstanceLoopCharacteristics isSequential="false|true">
  <loopCardinality>5</loopCardinality>
</multiInstanceLoopCharacteristics>

Expressions that resolve to a positive number are also possible:

<multiInstanceLoopCharacteristics isSequential="false|true">
  <loopCardinality>${nrOfOrders-nrOfCancellations}</loopCardinality>
</multiInstanceLoopCharacteristics>

Another way to define the number of instances, is to specify the name of a process variable which is a collection using the loopDataInputRef child element. For each item in the collection, an instance will be created. Optionally, it is possible to set that specific item of the collection for the instance using the inputDataItem child element. This is shown in the following XML example:

<userTask id="miTasks" name="My Task ${loopCounter}" activiti:assignee="${assignee}">
  <multiInstanceLoopCharacteristics isSequential="false">
    <loopDataInputRef>assigneeList</loopDataInputRef>
    <inputDataItem name="assignee" />
  </multiInstanceLoopCharacteristics>
</userTask>

Suppose the variable assigneeList contains the values [kermit, gonzo, foziee]. In the snippet above, three user tasks will be created in parallel. Each of the executions will have a process variable named assignee containing one value of the collection, which is used to assign the user task in this example.

The downside of the loopDataInputRef and inputDataItem is that 1) the names are pretty hard to remember and 2) due to the BPMN 2.0 schema restrictions they can't contain expressions. Activiti solves this by offering the collection and elementVariable attributes on the multiInstanceCharacteristics:

<userTask id="miTasks" name="My Task" activiti:assignee="${assignee}">
  <multiInstanceLoopCharacteristics isSequential="true"
     activiti:collection="${myService.resolveUsersForTask()}" activiti:elementVariable="assignee" >
  </multiInstanceLoopCharacteristics>
</userTask>

A multi-instance activity ends when all instances are finished. However, it is possible to specify an expression that is evaluated every time one instance ends. When this expression evaluates to true, all remaining instances are destroyed and the multi-instance activity ends, continuing the process. Such an expression must be defined in the completionCondition child element.

<userTask id="miTasks" name="My Task" activiti:assignee="${assignee}">
  <multiInstanceLoopCharacteristics isSequential="false"
     activiti:collection="assigneeList" activiti:elementVariable="assignee" >
    <completionCondition>${nrOfCompletedInstances/nrOfInstances >= 0.6 }</completionCondition>
  </multiInstanceLoopCharacteristics>
</userTask>

In this example, there will be parallel instances created for each element of the assigneeList collection. However, when 60% of the tasks are completed, the other tasks are deleted and the process continues.

Since a multi-instance is a regular activity, it is possible to define a boundary event on its boundary. In case of an interrupting boundary event, when the event is caught, all instances that are still active will be destroyed. Take for example following multi-instance subprocess:

Here, all instances of the subprocess will be destroyed when the timer fires, regardless of how many instances there are or which inner activities are currently not yet completed.

If an activity is used for compensating the effects of another activity, it can be declared to be a compensation handler. Compensation handlers are not contained in normal flow and are only executed when a compensation event is thrown.

Compensation handlers must not have incoming or outgoing sequence flows.

A compensation handler must be associated with a compensation boundary event using a directed association.

If an activity is a compensation handler, the compensation event icon is displayed in the center bottom area. The following excerpt from a process diagram shows a service task with an attached compensation boundary event which is associated to a compensation handler. Notice the compensation handler icon in the bottom canter area of the "cancel hotel reservation" service task

<serviceTask id="undoBookHotel" isForCompensation="true" activiti:class="...">
</serviceTask>

A subprocess is an activity that contains other activities, gateways, events, etc. which on itself form a process that is part of the bigger process. A subprocess is completely defined inside a parent process (that's why it's often called an embedded subprocess).

Subprocesses have two major use cases:

Using a subprocess does impose some constraints:

A subprocess is visualized as a typical activity, i.e. a rounded rectangle. In case the subprocess is collapsed, only the name and a plus-sign are displayed, giving a high-level overview of the process:

In case the subprocess is expanded, the steps of the subprocess are displayed within the subprocess boundaries:

One of the main reasons to use a subprocess, is to define a scope for a certain event. The following process model shows this: both the investigate software/investigate hardware tasks need to be done in parallel, but both tasks need to be done within a certain time, before Level 2 support is consulted. Here, the scope of the timer (i.e. which activities must be done in time) is constrained by the subprocess.

A subprocess is defined by the subprocess element. All activities, gateways, events, etc. that are part of the subprocess, need to be enclosed within this element.

<subProcess id="subProcess">

  <startEvent id="subProcessStart" />

  ... other subprocess elements ...

  <endEvent id="subProcessEnd" />

 </subProcess>


The event subprocess is new in BPMN 2.0. An event subprocess is a subprocess that is triggered by an event. An event subprocess can be added at the process level or at any subprocess level. The event used to trigger an event subprocess is configured using a start event. From this, it follows that none start events are not supported for event subprocesses. An event subprocess might be triggered using events lit message events, error events, signal events, timer events, or compensation events. The subscription to the start event is created when the scope (process instance or subprocess) hosting the event subprocess is created. The subscription is removed when the scope is destroyed.

An event subprocess may be interrupting or non interrupting. An interrupting subprocess cancels any executions in the current scope. A non interrupting event subprocess spawns a new concurrent execution. While an interrupting event subprocess can only be triggered once for each activation of the scope hosting it, a non interrupting event subprocess can be triggered multiple times. The fact whether the subprocess is interrupting is configured using the start event triggering the event subprocess.

An event subprocess must not have any incoming or outgoing sequence flows. Since an event subprocess is triggered by an event, an incoming sequence flow makes no sense. When an event subprocess is ended, either the current scope is ended (in case of an interrupting event subprocess), or the concurrent execution spawned for the non-interrupting subprocess is ended.

Current limitations:

An event subprocess might be visualized as a an embedded subprocess with a dotted outline.

An event subprocess is represented using xml in the same way as a an embedded subprocess. In addition the attribute triggeredByEvent must have the value true:

<subProcess id="eventSubProcess" triggeredByEvent="true">
	...
</subProcess>

The following is an example of an event subprocess triggered using an error start event. The event subprocess is located "at process level", i.e. is scoped to the process instance:

This is how the event subprocess would look like in XML:

<subProcess id="eventSubProcess" triggeredByEvent="true">
	<startEvent id="catchError">
		<errorEventDefinition errorRef="error" />
	</startEvent>
	<sequenceFlow id="flow2" sourceRef="catchError" targetRef="taskAfterErrorCatch" />
	<userTask id="taskAfterErrorCatch" name="Provide additional data" />
</subProcess>

As already stated, an event subprocess can also be added to an embedded subprocess. If it is added to an embedded subprocess, it becomes an alternative to a boundary event. Consider the two following process diagrams. In both cases the embedded subprocess throws an error event. Both times the error is caught and handled using a user task.

as opposed to:

In both cases the same tasks are executed. However, there are differences between both modelling alternatives:

These two differences can help you decide whether a boundary event or an embedded subprocess is better suited for solving a particular process modeling / implementation problem.

A transaction subprocess is an embedded subprocess, which can be used to group multiple activities to a transaction. A transaction is a logical unit of work which allows to group a set of individual activities, such that they either succeed or fail collectively.

Possible outcomes of a transaction: A transaction can have three different outcomes:

The following diagram illustrates the three different outcomes:

Relation to ACID transactions: it is important not to confuse the bpmn transaction subprocess with technical (ACID) transactions. The bpmn transaction subprocess is not a way to scope technical transactions. In order to understand transaction management in activiti, read the section on concurrency and transactions. A bpmn transaction is different from a technical transaction in the following ways:

Since bpmn transactions are long-running in nature, the lack of isolation and a rollback mechanism need to be dealt with differently. In practice, there is usually no better solution than to deal with these problems in a domain specific way:

To sum it up: while ACID transactions offer a generic solution to such problems (rollback, isolation levels and heuristic outcomes), we need to find domain specific solutions to these problems when implementing business transactions.

Current limitations:

Consistency on top of ACID transactions and optimistic concurrency: A bpmn transaction guarantees consistency in the sense that either all activities compete successfully, or if some activity cannot be performed, the effects of all other successful activities are compensated. So either way we end up in a consistent state. However, it is important to recognize that in activiti, the consistency model for bpmn transactions is superposed on top of the consistency model for process execution. Activiti executes processes in a transactional way. Concurrency is addressed using optimistic locking. In activiti, bpmn error, cancel and compensation events are built on top of the same acid transactions and optimistic locking. For example, a cancel end event can only trigger compensation if it is actually reached. It is not reached if some undeclared exception is thrown by a service task before. Or, the effects of a compensation handler can not be committed if some other participant in the underlying ACID transaction sets the transaction to the state rollback-only. Or, when two concurrent executions reach a cancel end event, compensation might be triggered twice and fail with an optimistic locking exception. All of this is to say that when implementing bpmn transactions in activiti, the same set of rules apply as when implementing "ordinary" processes and subprocesses. So to effectively guarantee consistency, it is important to implement processes in a way that does take the optimistic, transactional execution model into consideration.

An transaction subprocess might be visualized as a an embedded subprocess with a double outline.

A transaction subprocess is represented using xml using the transaction tag:

<transaction id="myTransaction" >
	...
</transaction>

The following is an example of a transaction subprocess:

BPMN 2.0 makes a distinction between a regular subprocess, often also called embedded subprocess, and the call activity, which looks very similar. From a conceptual point of view, both will call a subprocess when process execution arrives at the activity.

The difference is that the call activity references a process that is external to the process definition, whereas the subprocess is embedded within the original process definition. The main use case for the call activity is to have a reusable process definition that can be called from multiple other process definitions.

When process execution arrives in the call activity, a new execution is created that is a sub-execution of the execution that arrives in the call activity. This sub-execution is then used to execute the subprocess, potentially creating parallel child execution as within a regular process. The super-execution waits until the subprocess is completely ended, and continues the original process afterwards.

A call activity is visualized the same as a subprocess, however with a thick border (collapsed and expanded). Depending on the modeling tool, a call activity can also be expanded, but the default visualization is the collapsed subprocess representation.

A call activity is a regular activity, that requires a calledElement that references a process definition by its key. In practice, this means that the id of the process is used in the calledElement.

<callActivity id="callCheckCreditProcess" name="Check credit" calledElement="checkCreditProcess" />

Note that the process definition of the subprocess is resolved at runtime. This means that the subprocess can be deployed independently from the calling process, if needed.

You can pass process variables to the sub process and vice versa. The data is copied into the subprocess when it is started and copied back into the main process when it ends.

<callActivity id="callSubProcess" calledElement="checkCreditProcess" >
  <extensionElements>
	  <activiti:in source="someVariableInMainProcess" target="nameOfVariableInSubProcess" />
	  <activiti:out source="someVariableInSubProcss" target="nameOfVariableInMainProcess" />
  </extensionElements>
</callActivity>

We use an Activiti Extension as a shortcut for the BPMN standard elements called dataInputAssociation and dataOutputAssociation, which only work if you declare process variables in the BPMN 2.0 standard way.

It is possible to use expressions here as well:

<callActivity id="callSubProcess" calledElement="checkCreditProcess" >
	<extensionElements>
	  <activiti:in sourceExpression="${x+5}"" target="y" />
	  <activiti:out source="${y+5}" target="z" />
	</extensionElements>
</callActivity>

So in the end z = y+5 = x+5+5

The following process diagram shows a simple handling of an order. Since the checking of the customer's credit could be common to many other processes, the check credit step is modeled here as a call activity.

The process looks as follows:

<startEvent id="theStart" />
<sequenceFlow id="flow1" sourceRef="theStart" targetRef="receiveOrder" />

<manualTask id="receiveOrder" name="Receive Order" />
<sequenceFlow id="flow2" sourceRef="receiveOrder" targetRef="callCheckCreditProcess" />

<callActivity id="callCheckCreditProcess" name="Check credit" calledElement="checkCreditProcess" />
<sequenceFlow id="flow3" sourceRef="callCheckCreditProcess" targetRef="prepareAndShipTask" />

<userTask id="prepareAndShipTask" name="Prepare and Ship" />
<sequenceFlow id="flow4" sourceRef="prepareAndShipTask" targetRef="end" />

<endEvent id="end" />

The subprocess looks as follows:

There is nothing special to the process definition of the subprocess. It could as well be used without being called from another process.

Consider the following process definition:

We have a parallel gateway followed by three service tasks which all perform an asynchronous continuation. As a result of this, three jobs are added to the database. Once such a job is present in the database it can be processes by the JobExecutor. The JobExecutor acquires the jobs and delegates them to a thread pool of worker threads which actually process the jobs. This means that using an asynchronous continuation, you can distribute the work to this thread pool (and in a clustered scenario even across multiple thread pools in the cluster). This is usually a good thing. However it also bears an inherent problem: consistency. Consider the parallel join after the service tasks. When execution of a service tasks is completed, we arrive at the parallel join and need to decide whether to wait for the other executions or whether we can move forward. That means, for each branch arriving at the parallel join, we need to take a decision whether we can continue or whether we need to wait for one or more other executions on the other branches.

Why is this a problem? Since the service tasks are configured using an asynchronous continuation, it is possible that the corresponding jobs are all acquired at the same time and delegated to different worker threads by the JobExecutor. The consequence is that the transactions in which the services are executed and in which the 3 individual executions arrive at the parallel join can overlap. And if they do so, each individual transaction will not "see", that another transaction is arriving at the same parallel join concurrently and thus assume that it has to wait for the others. However, if each transaction assumes that it has to wait for the other ones, none will continue the process after the parallel join and the process instance will remain in that state forever.

How does activiti address this problem? Activiti performs optimistic locking. Whenever we take a decision based on data that might not be current (because another transaction might modify it before we commit, we make sure to increment the version of the same database row in both transactions). This way, whichever transaction commits first wins and the other ones fail with an optimistic locking exception. This solves the problem in the case of the process discussed above: if multiple executions arrive at the parallel join concurrently, they all assume that they have to wait, increment the version of their parent execution (the process instance) and then try to commit. Whichever execution is first will be able to commit and the other ones will fail with an optimistic locking exception. Since the executions are triggered by a job, activiti will retry to perform the same job after waiting for a certain amount of time and hopefully this time pass the synchronizing gateway.

Is this a good solution? As we have seen, optimistic locking allows activiti to prevent inconsistencies. It makes sure that we do not "keep stuck at the joining gateway", meaning: either all executions have passed the gateway or, there are jobs in the database making sure that we retry passing it. However, while this is a perfectly fine solution from the point of view of persistence and consistency, this might not always be desirable behavior at an higher level:

An exclusive job cannot be performed at the same time as another exclusive job from the same process instance. Consider the process shown above: if we declare the service tasks to be exclusive, the JobExecutor will make sure that the corresponding jobs are not executed concurrently. Instead, it will make sure that whenever it acquires an exclusive job from a certain process instance, it acquires all other exclusive jobs from the same process instance and delegates them to the same worker thread. This ensures sequential execution execution of the jobs.

How can I enable this feature? Since activiti 5.9, exclusive jobs are the default configuration. All asynchronous continuations and timer events are thus exclusive by default. In addition, if you want a job to be non-exclusive, you can configure it as such using activiti:exclusive="false". For example, the following servicetask would be asynchronous but non-exclusive.

<serviceTask id="service" activiti:expression="${myService.performBooking(hotel, dates)}" activiti:async="true" activiti:exclusive="false" />


Is this a good solution? We had some people asking whether this was a good solution. Their concern was that this would to prevent you from "doing things" in parallel and would thus be a performance problem. Again, two things have to be taken into consideration:

Download and extract Eclipse (Galileo or Helios should both work) and a recent version (3.x) of Apache Maven. If you use a 2.x version of Maven, you will run into problems when building your project, so make sure your version is up to date. We assume you are familiar with using basic features and the Java editor in Eclipse. It's up to you whether your prefer to use Eclipse's features for Maven or run Maven commands from a command prompt.

Create a new project in Eclipse. This can be a general project type. Create a pom.xml file at the root of the project to contain the Maven project setup. Also create folders for the src/main/java and src/main/resources folders, which are Maven conventions for your Java source files and resources respectively. Open the pom.xml file and add the following lines:

<project
  xmlns="http://maven.apache.org/POM/4.0.0"
  xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
  xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/maven-v4_0_0.xsd">

  <modelVersion>4.0.0</modelVersion>

  <groupId>org.acme</groupId>
  <artifactId>money-tasks</artifactId>
  <version>1.0.0</version>
  <packaging>jar</packaging>
  <name>Acme Corporation Money Tasks</name>
...
</pom>

As you can see, this is just a basic pom.xml file that defines a groupId, artifactId and version for the project. We will create a customization that includes a single custom node for our money business.

Add the integration library to your project's dependencies by including this dependency in your pom.xml file:

<dependencies>
  <dependency>
    <groupId>org.activiti</groupId>
    <artifactId>activiti-designer-integration</artifactId>
    <version>5.7</version> <!-- Current Activiti Designer Version -->
    <scope>compile</scope>
  </dependency>
</dependencies>
...
<repositories>
  <repository>
      <id>Activiti</id>
      <url>http://maven.alfresco.com/nexus/content/repositories/activiti/</url>
   </repository>
</repositories>

Finally, in the pom.xml file, add the configuration for the maven-compiler-plugin so the Java source level is at least 1.5 (see snippet below). You will need this in order to use annotations. You can also include instructions for Maven to generate the JAR's MANIFEST.MF file. This is not required, but you can use a specific property in the manifest to provide a name for your extension (this name may be shown at certain places in the designer and is primarily intended for future use if you have several extensions in the designer). If you wish to do so, include the following snippet in pom.xml:

<build>
  <plugins>
        <plugin>
      <artifactId>maven-compiler-plugin</artifactId>
      <configuration>
        <source>1.5</source>
        <target>1.5</target>
        <showDeprecation>true</showDeprecation>
        <showWarnings>true</showWarnings>
        <optimize>true</optimize>
      </configuration>
    </plugin>
    <plugin>
      <groupId>org.apache.maven.plugins</groupId>
      <artifactId>maven-jar-plugin</artifactId>
      <version>2.3.1</version>
      <configuration>
        <archive>
          <index>true</index>
          <manifest>
            <addClasspath>false</addClasspath>
            <addDefaultImplementationEntries>true</addDefaultImplementationEntries>
          </manifest>
          <manifestEntries>
            <ActivitiDesigner-Extension-Name>Acme Money</ActivitiDesigner-Extension-Name>
          </manifestEntries>
        </archive>
      </configuration>
    </plugin>
  </plugins>
</build>

The name for the extension is described by the ActivitiDesigner-Extension-Name property. The only thing left to do now is tell Eclipse to setup the project according to the instructions in pom.xml. So open up a command shell and go to the root folder of your project in the Eclipse workspace. Then execute the following Maven command:

mvn eclipse:eclipse

Wait until the build is successful. Refresh the project (use the project's context menu (right-click) and select Refresh). You should now have the src/main/java and src/main/resources folders as source folders in the Eclipse project.

That's it for the setup. Now you're ready to start creating customizations to Activiti Designer!

You might be wondering how you can add your extension to Activiti Designer so your customizations are applied. These are the steps to do just that:

Diagrams you open will now have the shapes from the new extension in their palette (or shapes disabled, depending on the customizations in your extension). If you already had a diagram opened, close and reopen it to see the changes in the palette.

With your project set up, you can now easily add shapes to the palette. Each shape you wish to add is represented by a class in your JAR. Take note that these classes are not the classes that will be used by the Activiti engine during runtime. In your extension you describe the properties that can be set in Activiti Designer for each shape. From these shapes, your refer to the runtime class that should be used by the engine. This class should implement JavaDelegate as for any ServiceTask in Activiti.

A shape's class is a simple Java class, to which a number of annotations are added. The class should implement the CustomServiceTask interface, but you shouldn't implement this interface yourself. Extend the AbstractCustomServiceTask base class instead (at the moment you MUST extend this class directly, so no abstract classes in between). In the Javadoc for that class you can find instructions on the defaults it provides and when you should override any of the methods it already implements. Overrides allow you to do things such as providing icons for the palette and in the shape on the canvas (these can be different) and specifying the base shape you want the node to have (activity, event, gateway).

/**
 * @author John Doe
 * @version 1
 * @since 1.0.0
 */
public class AcmeMoneyTask extends AbstractCustomServiceTask {
...
}

You will need to implement the getName() method to determine the name the node will have in the palette. You can also put the nodes in their own drawer and provide an icon. Override the appropriate methods from AbstractCustomServiceTask. If you want to provide an icon, make sure it's in the src/main/resources package in your JAR and is about 16x16 pixels and a JPEG or PNG format. The path you supply is relative to that folder.

You can add properties to the shape by adding members to the class and annotating them with the @Property annotation like this:

@Property(type = PropertyType.TEXT, displayName = "Account Number")
@Help(displayHelpShort = "Provide an account number", displayHelpLong = HELP_ACCOUNT_NUMBER_LONG)
private String accountNumber;

There are several PropertyType values you can use, which are described in more detail in this section. You can make a field required by setting the required attribute to true. A message and red background will appear if the user doesn't fill out the field.

If you want to ensure the order of the various properties in your class as they appear in the property screen, you should specify the order attribute of the @Property annotation.

As you can see, there's also an @Help annotation that's used to provide the user some guidance when filling out the field. You can also use the @Help annotation on the class itself - this information is shown at the top of the property sheet presented to the user.

Below is the listing for a further elaboration of the MoneyTask. A comment field has been added and you can see an icon is included for the node.

/**
 * @author John Doe
 * @version 1
 * @since 1.0.0
 */
@Runtime(delegationClass = "org.acme.runtime.AcmeMoneyJavaDelegation")
@Help(displayHelpShort = "Creates a new account", displayHelpLong = "Creates a new account using the account number specified")
public class AcmeMoneyTask extends AbstractCustomServiceTask {

  private static final String HELP_ACCOUNT_NUMBER_LONG = "Provide a number that is suitable as an account number.";

  @Property(type = PropertyType.TEXT, displayName = "Account Number", required = true)
  @Help(displayHelpShort = "Provide an account number", displayHelpLong = HELP_ACCOUNT_NUMBER_LONG)
  private String accountNumber;

  @Property(type = PropertyType.MULTILINE_TEXT, displayName = "Comments")
  @Help(displayHelpShort = "Provide comments", displayHelpLong = "You can add comments to the node to provide a brief description.")
  private String comments;

  /*
   * (non-Javadoc)
   *
   * @see org.activiti.designer.integration.servicetask.AbstractCustomServiceTask #contributeToPaletteDrawer()
   */
  @Override
  public String contributeToPaletteDrawer() {
    return "Acme Corporation";
  }

  @Override
  public String getName() {
    return "Money node";
  }

  /*
   * (non-Javadoc)
   *
   * @see org.activiti.designer.integration.servicetask.AbstractCustomServiceTask #getSmallIconPath()
   */
  @Override
  public String getSmallIconPath() {
    return "icons/coins.png";
  }
}

If you extend Activiti Designer with this shape, The palette and corresponding node will look like this:

The properties screen for the money task is shown below. Note the required message for the accountNumber field.

The help for fields is offered by the buttons to the right of each property. Clicking on the button shows a popup as displayed below.

The final step for your shape is to indicate the class that is instantiated by the Activiti engine when it reaches your node when executing a process instance. To do this, you use the @Runtime annotation. The delegationClass attribute you return should contain the canonical name of the runtime class. Note that the runtime class shouldn't be in your extension JAR, as it's dependent on the Activiti libraries.

@Runtime(delegationClass = "org.acme.runtime.AcmeMoneyJavaDelegation")

This section describes the property types you can use for a CustomServiceTask by setting its type to a PropertyType value.

PropertyType.TEXT

Creates a single line text field as shown below. Can be a required field and shows validation messages as a tooltip. Validation failures are displayed by changing the background of the field to a light red color.

PropertyType.MULTILINE_TEXT

Creates a multiline text field as shown below (height is fixed at 80 pixels). Can be a required field and shows validation messages as a tooltip. Validation failures are displayed by changing the background of the field to a light red color.

PropertyType.PERIOD

Creates a structured editor for specifying a period of time by editing amounts of each unit with a spinner control. The result is shown below. Can be a required field (which is interpreted such that not all values may be 0, so at least 1 part of the period must have a non-zero value) and shows validation messages as a tooltip. Validation failures are displayed by changing the background of the entire field to a light red color. The value of the field is stored as a string of the form 1y 2mo 3w 4d 5h 6m 7s, which represents 1 year, 2 months, 3 weeks, 4 days, 6 minutes and 7 seconds. The entire string is always stored, even if parts are 0.

PropertyType.BOOLEAN_CHOICE

Creates a single checkbox control for boolean or toggle choices. Note that you can specify the required attribute on the Property annotation, but it will not be evaluated because that would leave the user without a choice whether to check the box or not. The value stored in the diagram is java.lang.Boolean.toString(boolean), which results in "true" or "false".

PropertyType.RADIO_CHOICE

Creates a group of radio buttons as shown below. Selection of any of the radio buttons is mutually exclusive with selection of any of the others (i.e., only one selection allowed). Can be a required field and shows validation messages as a tooltip. Validation failures are displayed by changing the background of the group to a light red color.

This property type expects the class member you have annotated to also have an accompanying @PropertyItems annotation (for an example, see below). Using this additional annotation, you can specify the list of items that should be offered in an array of Strings. Specify the items by adding two array entries for each item: first, the label to be shown; second, the value to be stored.

@Property(type = PropertyType.RADIO_CHOICE, displayName = "Withdrawl limit", required = true)
@Help(displayHelpShort = "The maximum daily withdrawl amount ", displayHelpLong = "Choose the maximum daily amount that can be withdrawn from the account.")
@PropertyItems({ LIMIT_LOW_LABEL, LIMIT_LOW_VALUE, LIMIT_MEDIUM_LABEL, LIMIT_MEDIUM_VALUE, LIMIT_HIGH_LABEL, LIMIT_HIGH_VALUE })
private String withdrawlLimit;

PropertyType.COMBOBOX_CHOICE

Creates a combobox with fixed options as shown below. Can be a required field and shows validation messages as a tooltip. Validation failures are displayed by changing the background of the combobox to a light red color.

This property type expects the class member you have annotated to also have an accompanying @PropertyItems annotation (for an example, see below). Using this additional annotation, you can specify the list of items that should be offered in an array of Strings. Specify the items by adding two array entries for each item: first, the label to be shown; second, the value to be stored.

@Property(type = PropertyType.COMBOBOX_CHOICE, displayName = "Account type", required = true)
@Help(displayHelpShort = "The type of account", displayHelpLong = "Choose a type of account from the list of options")
@PropertyItems({ ACCOUNT_TYPE_SAVINGS_LABEL, ACCOUNT_TYPE_SAVINGS_VALUE, ACCOUNT_TYPE_JUNIOR_LABEL, ACCOUNT_TYPE_JUNIOR_VALUE, ACCOUNT_TYPE_JOINT_LABEL,
  ACCOUNT_TYPE_JOINT_VALUE, ACCOUNT_TYPE_TRANSACTIONAL_LABEL, ACCOUNT_TYPE_TRANSACTIONAL_VALUE, ACCOUNT_TYPE_STUDENT_LABEL, ACCOUNT_TYPE_STUDENT_VALUE,
  ACCOUNT_TYPE_SENIOR_LABEL, ACCOUNT_TYPE_SENIOR_VALUE })
private String accountType;

PropertyType.DATE_PICKER

Creates a date selection control as shown below. Can be a required field and shows validation messages as a tooltip (note, that the control used will auto-set the selection to the date on the system, so the value is seldom empty). Validation failures are displayed by changing the background of the control to a light red color.

This property type expects the class member you have annotated to also have an accompanying @DatePickerProperty annotation (for an example, see below). Using this additional annotation, you can specify the date time pattern to be used to store dates in the diagram and the type of datepicker you would like to be shown. Both attributes are optional and have default values that will be used if you don't specify them (these are static variables in the DatePickerProperty annotation). The dateTimePattern attribute should be used to supply a pattern to the SimpleDateFormat class. When using the swtStyle attribute, you should specify an integer value that is supported by SWT's DateTime control, because this is the control that is used to render this type of property.

@Property(type = PropertyType.DATE_PICKER, displayName = "Expiry date", required = true)
@Help(displayHelpShort = "The date the account expires ", displayHelpLong = "Choose the date when the account will expire if no extended before the date.")
@DatePickerProperty(dateTimePattern = "MM-dd-yyyy", swtStyle = 32)
private String expiryDate;

PropertyType.DATA_GRID

Creates a data grid control as shown below. A data grid can be used to allow the user to enter an arbitrary amount of rows of data and enter values for a fixed set of columns in each of those rows (each individual combination of row and column is referred to as a cell). Rows can be added and removed as the user sees fit.

This property type expects the class member you have annotated to also have an accompanying @DataGridProperty annotation (for an example, see below). Using this additional annotation, you can specify some specific attributes of the data grid. You are required to reference a different class to determine which columns go into the grid with the itemClass attribute. Activiti Designer expects the member type to be a List. By convention, you can use the class of the itemClass attribute as its generic type. If, for example, you have a grocery list that you edit in the grid, you would define the columns of the grid in the GroceryListItem class. From your CustomServiceTask, you would refer to it like this:

@Property(type = PropertyType.DATA_GRID, displayName = "Grocery List")
@DataGridProperty(itemClass = GroceryListItem.class)
private List<GroceryListItem> groceryList;

The "itemClass" class uses the same annotations you would otherwise use to specify fields of a CustomServiceTask, with the exception of using a data grid. Specifically, TEXT, MULTILINE_TEXT and PERIOD are currently supported. You'll notice the grid will create single line text controls for each field, regardless of the PropertyType. This is done on purpose to keep the grid graphically appealing and readable. If you consider the regular display mode for a PERIOD PropertyType for instance, you can imagine it would never properly fit in a grid cell without cluttering the screen. For MULTILINE_TEXT and PERIOD, a double-click mechanism is added to each field which pops up a larger editor for the PropertyType. The value is stored to the field after the user clicks OK and is therefore readable within the grid.

Required attributes are handled in a similar manner to regular fields of type TEXT and the entire grid is validated as soon as any field loses focus. The background color of the text control in a specific cell of the data grid is changed to light red if there are validation failures.

By default, the component allows the user to add rows, but not to determine the order of those rows. If you wish to allow this, you should set the orderable attribute to true, which enables buttons at the end of each row to move it up or down in the grid.

Note

At the moment, this property type is not correctly injected into your runtime class.

This customization requires you to include a class in your extension that implements the DefaultPaletteCustomizer interface. You should not implement this interface directly, but subclass the AbstractDefaultPaletteCustomizer base class. Currently, this class provides no functionality, but future versions of the DefaultPaletteCustomizer interface will offer more capabilities for which this base class will provide some sensible defaults so it's best to subclass so your extension will be compatible with future releases.

Extending the AbstractDefaultPaletteCustomizer class requires you to implement one method, disablePaletteEntries(), from which you must return a list of PaletteEntry values. For each of the default shapes, you can disable it by adding its corresponding PaletteEntry value to your list. Note that if you remove shapes from the default set and there are no remaining shapes in a particular drawer, that drawer will be removed from the palette in its entirety. If you wish to disable all of the default shapes, you only need to add PaletteEntry.ALL to your result. As an example, the code below disables the Manual task and Script task shapes in the palette.

public class MyPaletteCustomizer extends AbstractDefaultPaletteCustomizer {

  /*
   * (non-Javadoc)
   *
   * @see org.activiti.designer.integration.palette.DefaultPaletteCustomizer#disablePaletteEntries()
   */
  @Override
  public List<PaletteEntry> disablePaletteEntries() {
    List<PaletteEntry> result = new ArrayList<PaletteEntry>();
    result.add(PaletteEntry.MANUAL_TASK);
    result.add(PaletteEntry.SCRIPT_TASK);
    return result;
  }

}

The result of applying this extension is shown in the picture below. As you can see, the manual task and script task shapes are no longer available in the Tasks drawer.

To disable all of the default shapes, you could use something similar to the code below.

public class MyPaletteCustomizer extends AbstractDefaultPaletteCustomizer {

  /*
   * (non-Javadoc)
   *
   * @see org.activiti.designer.integration.palette.DefaultPaletteCustomizer#disablePaletteEntries()
   */
  @Override
  public List<PaletteEntry> disablePaletteEntries() {
    List<PaletteEntry> result = new ArrayList<PaletteEntry>();
    result.add(PaletteEntry.ALL);
    return result;
  }

}

The result will look like this (notice that the drawers the default shapes were in are no longer in the palette):

Create an extension to the org.activiti.designer.eclipse.extension.validation.ProcessValidator extension point in your plugin.xml file. For this extension point, you are required to subclass the AbstractProcessValidator class.

<?eclipse version="3.6"?>
<plugin>
  <extension
    point="org.activiti.designer.eclipse.extension.validation.ProcessValidator">
    <ProcessValidator
      class="org.acme.validation.AcmeProcessValidator">
    </ProcessValidator>
  </extension>
</plugin>

public class AcmeProcessValidator extends AbstractProcessValidator {
}

You have to implement a number of methods. Most importantly, implement getValidatorId() so you return a globally unique ID for your validator. This will enable you to invoke it from and ExportMarshaller, or event let someone else invoke your validator from their ExportMarshaller. Implement getValidatorName() and return a logical name for your validator. This name is shown to the user in dialogs. In getFormatName(), you can return the type of diagram the validator typically validates.

The validation work itself is done in the validateDiagram() method. From this point on, it's up to your specific functionality what you code here. Typically, however, you will want to start by getting hold of the nodes in the diagram's process, so you can iterate through them, collect, compare and validate data. This snippet shows you how to do this:

final EList<EObject> contents = getResourceForDiagram(diagram).getContents();
for (final EObject object : contents) {
  if (object instanceof StartEvent ) {
  // Perform some validations for StartEvents
  }
  // Other node types and validations
}

Don't forget to invoke addProblemToDiagram() and/or addWarningToDiagram(), etc as you go through your validations. Make sure you return a correct boolean result at the end to indicate whether you consider the validation as succeeded or failed. This can be used by and invoking ExportMarshaller to determine the next course of action.

Create an extension to the org.activiti.designer.eclipse.extension.export.ExportMarshaller extension point in your plugin.xml file. For this extension point, you are required to subclass the AbstractExportMarshaller class. This abstract base class provides you with a number of useful methods when marshalling to your own format, but most importantly it allows you to save resources to the workspace and to invoke validators.

<?eclipse version="3.6"?>
<plugin>
  <extension
    point="org.activiti.designer.eclipse.extension.export.ExportMarshaller">
    <ExportMarshaller
      class="org.acme.export.AcmeExportMarshaller">
    </ExportMarshaller>
  </extension>
  </plugin>

public class AcmeExportMarshaller extends AbstractExportMarshaller {
}

You are required to implement some methods, such as getMarshallerName() and getFormatName(). These methods are used to display options to the user and to show information in progress dialogs, so make sure the descriptions you return reflect the functionality you are implementing.

The bulk of your work is performed in the marshallDiagram(Diagram diagram, IProgressMonitor monitor) method. You are provided with the diagram object, which contains all of the information about the objects in the diagram (BPMN constructs) and the graphical representation.

If you want to perform a certain validation first, you can invoke the validator directly from your marshaller. You receive a boolean result from the validator, so you know whether validation succeeded. In most cases you won't want to proceed with marshalling the diagram if it's not valid, but you might choose to go ahead anyway or even create a different resource if validation fails. For example:

final boolean validDiagram = invokeValidator(AcmeConstants.ACME_VALIDATOR_ID, diagram, monitor);
if (!validDiagram) {
  addProblemToDiagram(diagram, "Marshalling to " + getFormatName() + " format was skipped because validation of the diagram failed.", null);
} else {
  //proceed with marshalling
}

As you can see, here we have chosen to cancel the marshalling if the validator (identified by a constant here) returns false as result. We have also added an additional marker to the diagram so the user can see an explanation why the file wasn't created. This is not required, but seems helpful to the user and shows how you can use these utilities from both ProcessValidators and ExportMarshallers.

Once you have all the data you need, you should invoke the saveResource() method to create a file containing your data. You can invoke saveResource() as many times as you wish from a single ExportMarshaller; a marshaller can therefore be used to create more than one output file.

You can construct a filename for your output resource(s) by using some of the methods in the AbstractDiagramWorker class. There are a couple of useful variables you can have parsed, allowing you to create filenames such as <original-filename>_<my-format-name>.xml. These variables are described in the Javadocs, but here's an example how to use one of them:

private static final String FILENAME_PATTERN = ExportMarshaller.PLACEHOLDER_ORIGINAL_FILENAME + ".acme.axml";
...
saveResource(getRelativeURIForDiagram(diagram, FILENAME_PATTERN), bais, this.monitor);

What happens here is that a static member is used to describe the filename pattern (this is just a best practice, you can specify the string any way you like of course) and the pattern uses the ExportMarshaller.PLACEHOLDER_ORIGINAL_FILENAME constant to insert a variable for the original filename. Later on in the marshallDiagram() method, getRelativeURIForDiagram() is invoked and it will parse the filename for any variables and substitute them. You provide saveResource() with an InputStream to your data and it will save the data to a resource with a relative path to the original diagram.

Again, you should also use the progress monitor provided to report your progress back to the user. How to do this is described in this article.
